Motor Drive Roller
/
AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of Pallets

AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of Pallets

Brand Name: Winroller
Model Number: Winroller AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller
MOQ: 1stick
Price: Contact Us
Packaging Details: Wooden case
Payment Terms: TT, L/C
Detail Information
Place of Origin:
China Jiangsu
Certification:
CE,SGS,ISO9001,ROHS,UL
Features:
High Torque, Heavy Load, Capable Of Driving 3 Tons Of Tray
Product Name:
AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller
Motor Type:
AC Asynchronous Gear Reduction Motor
Maximum Load:
3000kg
Output Power:
300W
Drive Mode:
Double Sprocket
Diameter:
60mm, 76mm, 82mm
Voltage:
1ph220V, 3PH220V, 3PH380V
Speed Range:
7~70m/min
Cylinder Material:
Galvanized Carbon Steel, Stainless Steel
Application:
Warehouse Automation, Manufacturing Lines, Logistics And Distribution Centers, Automotive Industry, Heavy Equipment, Packaging Systems
Supply Ability:
1000000/year
Highlight:

Pallet Conveyor Roller 3000kg

,

High Torque Electric Drive Roller

,

Electric Drive Roller 3000kg

Product Description

AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of Pallets

Features Overview of AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller

The AC High Torque Electric Power Roller is designed for heavy-duty applications, featuring a robust construction capable of handling loads up to 3 tons. With a diameter of 76 mm and adjustable line speeds ranging from 7 to 70 m/min, it ensures efficient operation. Available in various voltage options (1ph 220V, 3ph 220V, 3ph 380V) and materials like galvanized carbon steel or stainless steel, it is suitable for diverse environments. Its high torque capabilities make it ideal for demanding logistics and conveyor systems.



Function of AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller

The AC High Torque Electric Power Roller is designed to provide powerful and efficient movement of heavy loads, capable of handling weights up to 3 tons. With a diameter of 76 mm and adjustable line speeds ranging from 7 to 70 m/min, it ensures optimal performance for various industrial applications.



Equipped with high torque output, this roller allows for reliable operation even under demanding conditions. Its robust construction, available in both galvanized carbon steel and stainless steel, offers exceptional durability and resistance to wear, making it suitable for environments with harsh operating conditions.



Additionally, the motor is compatible with multiple voltage options—1ph 220V, 3ph 220V, and 3ph 380V—enhancing its versatility for integration into diverse conveyor systems. With features such as easy installation and maintenance-free operation, this drum motor roller delivers an ultimate solution for heavy-duty logistics and material handling operations, maximizing efficiency and productivity.





Application of AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller

  • Warehouse automation
  • Manufacturing Lines
  • Logistics and Distribution Centers
  • Automotive Industry
  • Heavy Equipment
  • Packaging Systems



Technical Parameters of AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller



AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller
Diameter 60mm, 76mm, 82mm Maximum Load 3000kg
Motor Type AC Asynchronous Gear Reduction Motor Output Power 300W
Drive Mode Double sprocket Voltage 1ph220V, 3PH220V, 3PH380V
Speed Range 7~70m/min Cylinder Material Galvanized carbon steel, stainless steel
Application Warehouse automation, manufacturing lines, logistics and distribution centers, automotive industry, heavy equipment, packaging systems
Features High torque, heavy load, capable of driving 3 tons of tray



AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of Pallets



Feature Picture of AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller

AC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of PalletsAC High Torque Electric Power Roller Load Heavy Duty Drum Motor Roller Drive 3000kg Of Pallets
